Mounting details with IP40 of protection from the front Ordering no #6 Notes and rules
No mounting kit included X
19" rack mounting kit for 1/2 x 19" case or 2xRHGS6 or RHGS12 1MRK002420-BB A
19" rack mounting kit for 3/4 x 19" case or 3xRHGS6 1MRK002420-BA B
19" rack mounting kit for 1/1 x 19" case 1MRK002420-CA C
Wall mounting kit 1MRK002420-DA D Wall mounting not recommended
with communication modules with
fibre connection
Flush mounting kit 1MRK002420-PA E
Flush mounting kit + IP54 mounting seal 1MRK002420-NA F
Selection for
position #6
Power supply modules Ordering no #7 Notes and rules
Compression terminals 1MRK002960-GA C
Ringlug terminals 1MRK002960-HA R
Power supply module, 24-60 VDC 1MRK002239-AB A
Power supply module, 90-250 VDC 1MRK002239-BB B
Selection for
position #7
Human machine hardware interface Ordering no #8 Notes and rules
Medium size - graphic display, IEC keypad symbols 1MRK000028-AA B
Medium size - graphic display, ANSI keypad symbols 1MRK000028-AB C
Selection for
position #8
Analog system Ordering no #9 Notes and rules
Slot position (front view/rear view) P40/X401
No Transformer input module included X0 Only valid if IEC 61850-9-2
Process bus communication is
selected.
TRM 7I 1A + 5U 110/220V, 50/60Hz, compression terminals 1MRK002247-AP A12
TRM 7I 5A + 5U 110/220V, 50/60Hz, compression terminals 1MRK002247-AR A13
TRM 6I 5A + 1I 1A + 5U 110/220V, 50/60Hz, compression terminals 1MRK002247-AU A14
TRM 3I 5A + 4I 1A + 5U 110/220V, 50/60Hz, compression terminals 1MRK002247-AV A15
TRM 7I 1A + 5U 110/220V, 50/60Hz, ring lug terminals 1MRK002247-AS B12
TRM 7I 5A + 5U 110/220V, 50/60Hz, ring lug terminals 1MRK002247-AT B13
TRM 6I 5A + 1I 1A + 5U 110/220V, 50/60Hz, ring lug terminals 1MRK002247-AX B14
TRM 3I 5A + 4I 1A + 5U 110/220V, 50/60Hz, ring lug terminals 1MRK002247-AY B15
Selection for
position #9
1MRK 506 384-BEN A
Line distance protection REL650 2.2
Product version: 2.2.1
84 ABB
