Binary input/output modules Ordering no #10 Notes and rules
For pulse counting, for example kWh metering, the BIM with enhanced pulse counting capabilities must be used.
Note: 1 BIM required in position P3 and 1 BOM always included in position P4.
Slot position (front view/rear view)
P3/X31 P4/X41 P5/X51
Max 3 positions in 1/2 rack
1/2 case with 1 TRM █ █ █
Compression terminals 1MRK002960-KA C
No board in slot X
Binary output module 24 output relays (BOM) 1MRK000614-AB A A
BIM 16 inputs, RL24, 24-30VDC, 50mA 1MRK000508-DD B1 B1
BIM 16 inputs, RL48, 48-60VDC, 50mA 1MRK000508-AD C1 C1
BIM 16 inputs, RL110, 110-125VDC, 50mA 1MRK000508-BD D1 D1
BIM 16 inputs, RL220, 220-250VDC, 50mA 1MRK000508-CD E1 E1
BIM 16 inputs, RL220, 220-250VDC, 120mA 1MRK000508-CE E2 E2
BIM 16 inputs, RL24, 24-30VDC, 50mA, enhanced pulse counting 1MRK000508-HA F
BIM 16 inputs, RL48, 48-60VDC, 50mA, enhanced pulse counting 1MRK000508-EA G
BIM 16 inputs, RL110, 110-125VDC, 50mA, enhanced pulse
counting
1MRK000508-FA H
BIM 16 inputs, RL220, 220-250VDC, 50mA, enhanced pulse
counting
1MRK000508-GA K
IOM 8 inputs, 10+2 outputs, RL24, 24-30VDC, 50mA 1MRK000173-GD L1
IOM 8 inputs, 10+2 outputs, RL48, 48-60VDC, 50mA 1MRK000173-AE M1
IOM 8 inputs, 10+2 outputs, RL110, 110-125VDC, 50mA 1MRK000173-BE N1
IOM 8 inputs, 10+2 outputs, RL220, 220-250VDC, 50mA 1MRK000173-CE P1
IOM 8 inputs 10+2 outputs, RL220, 220-250VDC, 110mA 1MRK000173-CF P2
IOM with MOV 8 inputs, 10+2 outputs, RL24, 24-30VDC, 50mA 1MRK000173-GC U
IOM with MOV 8 inputs, 10+2 outputs, RL48, 48-60VDC, 50mA 1MRK000173-AD V
IOM with MOV 8 inputs, 10+2 outputs, RL110, 110-125VDC, 50mA 1MRK000173-BD W
IOM with MOV 8 inputs, 10+2 outputs, RL220, 220-250VDC, 50mA 1MRK000173-CD Y
Selection for
position #10
C
Station communication and time synchronization Ordering no #11 Notes and rules
Slot position (front view/rear view)
P30:1/X301 P30:2/X302 P30:3/X303
P30:4/X304
P30:6:1/X3061
P30:6:2/X3062
P31:1/X311 P31:2/X312 P31:3/X313
LDCM mode
Available slots in 1/2 case with 1 TRM █ █ █ █ █ █ █ █ █
No communication board included X X X X X X X X X
Ethernet SFP, optical LC connector 1MRK005500-AA K K K K Ethernet SFP is basic in
P30:1.
Ethernet SFP, RJ45 connector 1MRK005500-BA P P P P
Serial SPA/LON/DNP/IEC 60870-5-103 plastic
interface
1MRK001608-AB L
Serial SPA/LON/DNP/IEC 60870-5-103 plastic/
glass interface
1MRK001608-BB M
Serial SPA/LON/DNP/IEC 60870-5-103 glass
interface
1MRK001608-CB N
Galvanic RS485 communication module 1MRK002309-AA G G
Line data communication, default 64kbps mode — X LDCM is not applicable.
IRIG-B time synchronization module 1MRK002305-AA F F
Selection for
position #11
K X
1MRK 506 384-BEN A
Line distance protection REL650 2.2
Product version: 2.2.1
