Functionality IEC 61850 IEC 60617 IEC-ANSI
Master trip, instance 2 TRPPTRC2 Master Trip (2) 94/86 (2)
Control
Circuit-breaker control CBXCBR1 I ↔ O CB I ↔ O CB
Disconnector position indication,
instance 1
DCSXSWI1 I ↔ O DC (1) I ↔ O DC (1)
Disconnector position indication,
instance 2
DCSXSWI2 I ↔ O DC (2) I ↔ O DC (2)
Disconnector position indication,
instance 3
DCSXSWI3 I ↔ O DC (3) I ↔ O DC (3)
Earthing switch indication ESSXSWI1 I ↔ O ES I ↔ O ES
Auto-reclosing DARREC1 O → I 79
Condition Monitoring
Circuit-breaker condition monitoring SSCBR1 CBCM CBCM
Trip circuit supervision, instance 1 TCSSCBR1 TCS (1) TCM (1)
Trip circuit supervision, instance 2 TCSSCBR2 TCS (2) TCM (2)
Current circuit supervision CCRDIF1 MCS 3I MCS 3I
Protection communication supervision PCSRTPC1 PCS PCS
Measurement
Disturbance recorder RDRE1 - -
Three-phase current measurement,
instance 1
CMMXU1 3I 3I
Sequence current measurement CSMSQI1
I
1
, I
2
, I
0
I
1
, I
2
, I
0
Residual current measurement, instance
1
RESCMMXU1
I
0
I
n
Residual voltage measurement RESVMMXU1
U
0
V
n
