ABB Rellon 620 Series Technical Manual

Section 9 1MAC309294-MB F
Other functions
446 RER620
Technical Manual
Table 400: PTGAPC Output signals
9.5.4 Settings
Table 401: PTGAPC Non group settings
Table 402: Generic timers, TPGAPC1...4
Table 403: Generic timers, TPSGAPC1
Table 404: Generic timers, TPMGAPC1
9.5.5 Technical data
Table 405: PTGAPC Technical data
Name Type Description
Q1 BOOLEAN Output 1 status
Q2 BOOLEAN Output 2 status
Q3 BOOLEAN Output 3 status
Q4 BOOLEAN Output 4 status
Q5 BOOLEAN Output 5 status
Q6 BOOLEAN Output 6 status
Q7 BOOLEAN Output 7 status
Q8 BOOLEAN Output 8 status
Parameter Values (Range) Unit Step Default Description
Pulse delay time 1 0...3600000 ms 10 0 Pulse delay time
Pulse delay time 2 0...3600000 ms 10 0 Pulse delay time
Pulse delay time 3 0...3600000 ms 10 0 Pulse delay time
Pulse delay time 4 0...3600000 ms 10 0 Pulse delay time
Pulse delay time 5 0...3600000 ms 10 0 Pulse delay time
Pulse delay time 6 0...3600000 ms 10 0 Pulse delay time
Pulse delay time 7 0...3600000 ms 10 0 Pulse delay time
Pulse delay time 8 0...3600000 ms 10 0 Pulse delay time
Parameter Values (Range) Unit Step Default Description
Pulse time 0...60000 ms 1 150 Minimum pulse time
Parameter Values (Range) Unit Step Default Description
Pulse time 0...300 s 1 0 Minimum pulse time, range in seconds
Parameter Values (Range) Unit Step Default Description
Pulse time 0...300 min 1 0 Minimum pulse time, range in minutes
Characteristic Value
Operate time
accuracy
±1.0% of the set
value or ±20 ms
