ABB RTU560 User Manual

RTU560

Connections and Settings
Communication Unit 560CMD11
Doc.-No.: 1KGT 150 765 V005 1 6
Firmware Version
The current firmware version will be delivered on
a CompactFlash memory card. A new firmware
file can be loaded via the Web diagnostic tool into
the removable CompactFlash memory card.
For changing the CompactFlash memory card the
right side of the housing has to be opened (see
Fig. 8 and Fig. 11).
!!
1. Disconnect the power-supply of the
560CMD11.
2. Take care of ESD protection before
opening the 560CMD11 housing.
3. Open the 4 screws on the right side of
the housing (see Fig. 8 and Fig. 11).
4. Pull or plug only the CF-card. Don’t
touch other components.
5. Close the housing before the power-
supply is connected to the 560CMD11
SIM-Card (only R0011)
For communication via the GSM/GPRS modem a
pluggable SIM-Card (ID-000) is necessary.
For changing the SIM-Card the right side of the
housing has to be opened (see Fig. 11).
!!
1. Disconnect the power-supply of the
560CMD11.
2. Take care of ESD protection before
opening the 560CMD11 housing.
3. Open the 4 screws on the right side of
the housing (see Fig. 11).
4. Pull or plug only the SIM-Card. Don’t
touch other components.
5. Close the housing before the power-
supply is connected to the 560CMD11
For changing the CF - card
follow the instructions below:
For changing the SIM-Card
follow the instructions below:

ABB RTU560 Specifications

General

Category	Remote Terminal Unit (RTU)
Manufacturer	ABB
Model	RTU560
Communication Ports	Ethernet, Serial, USB
Operating Temperature	-40°C to +70°C
Mounting	DIN rail
Communication Protocols	IEC 60870-5-101, IEC 60870-5-104, DNP3, Modbus
Certifications	UL
Power Supply	24V DC or 110-230V AC
