ABB VD4/R User Manual

13
5.4.2. Types available circuit-breakers for ABB switchgear
Pole centre distance Technical documentation
U [kV] In [A] Isc [kA] Description 230 mm Dimensions Electrical diagram
12 630 12.5 VD4/UniMix-F 12.06.12
16 VD4/UniMix-F 12.06.16
20 VD4/UniMix-F 12.06.20
25 VD4/UniMix-F 12.06.25
17.5 630 12.5 VD4/UniMix-F 17.06.12
16 VD4/UniMix-F 17.06.16
20 VD4/UniMix-F 17.06.20
25 VD4/UniMix-F 17.06.25
24 630 12.5 VD4/UniMix-F 24.06.12
16 VD4/UniMix-F 24.06.16
20 VD4/UniMix-F 24.06.20
VD4/UniMix-F 12-17-24 (right lateral operating mechanism; version for UniMix switchgear P1/F unit both IP30,
and Arc-proof; circuit-breaker without wheels and cabled to terminal box)
Pole centre distance Technical documentation
U [kV] In [A] Isc [kA] Description 210 mm Dimensions Electrical diagram
12 630 12.5 VD4/S 12.06.12
16 VD4/S 12.06.16
20 VD4/S 12.06.20
25 VD4/S 12.06.25
800 12.5 VD4/S 12.08.12
16 VD4/S 12.08.16
20 VD4/S 12.08.20
25 VD4/S 12.08.25
1250 12.5 VD4/S 12.12.12
16 VD4/S 12.12.16
20 VD4/S 12.12.20
25 VD4/S 12.12.25
17.5 630 12.5 VD4/S 17.06.12
16 VD4/S 17.06.16
20 VD4/S 17.06.20
800 12.5 VD4/S 17.08.12
16 VD4/S 17.08.16
20 VD4/S 17.08.20
1250 12.5 VD4/S 17.12.12
16 VD4/S 17.12.16
20 VD4/S 17.12.20
24 630 12.5 VD4/S 24.06.12
16 VD4/S 24.06.16
20 VD4/S 24.06.20
800 12.5 VD4/S 24.08.12
16 VD4/S 24.08.16
20 VD4/S 24.08.20
1250 12.5 VD4/S 24.12.12
16 VD4/S 24.12.16
20 VD4/S 24.12.20
VD4/S 12-17-24 (right lateral operating mechanism; version for UniSwitch switchgear)
1VCD4000971VCD000106
1VCD4000971VCD000106
1VCD4000971VCD000106
1VCD4000981VCD000098
1VCD4000981VCD000098
1VCD4000981VCD000098
