ABB VD4/R User Manual

14
Pole centre distance Technical documentation
U [kV] In [A] Isc [kA] Description 230 mm Dimensions Electrical diagram
12 630 12.5 VD4/UniMix-R 12.06.12
16 VD4/UniMix-R 12.06.16
20 VD4/UniMix-R 12.06.20
25 VD4/UniMix-R 12.06.25
17.5 630 12.5 VD4/UniMix-R 17.06.12
16 VD4/UniMix-R 17.06.16
20 VD4/UniMix-R 17.06.20
25 VD4/UniMix-R 17.06.25
24 630 12.5 VD4/UniMix-R 24.06.12
16 VD4/UniMix-R 24.06.16
20 VD4/UniMix-R 24.06.20
VD4/UniMix-R 12-17-24 (right lateral operating mechanism; version for UniMix switchgear P1/F unit both IP30,
and Arc-proof; circuit-breaker with wheels and fitted with power cord with 58-pole plug)
Pole centre distance Technical documentation
U [kV] In [A] Isc [kA] Description 300 mm Dimensions Electrical diagram
12 630 12.5 VD4/UniAir 12.06.12
16 VD4/UniAir 12.06.16
20 VD4/UniAir 12.06.20
25 VD4/UniAir 12.06.25
800 16 VD4/UniAir 12.08.16
20 VD4/UniAir 12.08.20
25 VD4/UniAir 12.08.25
1250 16 VD4/UniAir 12.12.16
20 VD4/UniAir 12.12.20
25 VD4/UniAir 12.12.25
17.5 630 12.5 VD4/UniAir 17.06.12
16 VD4/UniAir 17.06.16
20 VD4/UniAir 17.06.20
800 16 VD4/UniAir 17.08.16
20 VD4/UniAir 17.08.20
1250 16 VD4/UniAir 17.12.16
20 VD4/UniAir 17.12.20
24 630 12.5 VD4/UniAir 24.06.12
16 VD4/UniAir 24.06.16
20 VD4/UniAir 24.06.20
800 16 VD4/UniAir 24.08.16
20 VD4/UniAir 24.08.20
1250 16 VD4/UniAir 24.12.16
20 VD4/UniAir 24.12.20
VD4/UniAir 12-17-24 (right lateral operating mechanism; version for UniAir switchgear P1/E unit - IP30 version –
unit with circuit-breaker withdrawable on the supply side)
Pole centre distance Technical documentation
U [kV] In [A] Isc [kA] Description 300 mm Dimensions Electrical diagram
12 630 12.5 VD4/UniAir-2R 12.06.12
16 VD4/UniAir-2R 12.06.16
20 VD4/UniAir-2R 12.06.20
25 VD4/UniAir-2R 12.06.25
800 16 VD4/UniAir-2R 12.08.16
20 VD4/UniAir-2R 12.08.20
25 VD4/UniAir-2R 12.08.25
1250 16 VD4/UniAir-2R 12.12.16
20 VD4/UniAir-2R 12.12.20
25 VD4/UniAir-2R 12.12.25
17.5 630 12.5 VD4/UniAir-2R 17.06.12
16 VD4/UniAir-2R 17.06.16
20 VD4/UniAir-2R 17.06.20
800 16 VD4/UniAir-2R 17.08.16
20 VD4/UniAir-2R 17.08.20
1250 16 VD4/UniAir-2R 17.12.16
20 VD4/UniAir-2R 17.12.20
24 630 12.5 VD4/UniAir-2R 24.06.12
16 VD4/UniAir-2R 24.06.16
20 VD4/UniAir-2R 24.06.20
800 16 VD4/UniAir-2R 24.08.16
20 VD4/UniAir-2R 24.08.20
1250 16 VD4/UniAir-2R 24.12.16
20 VD4/UniAir-2R 24.12.20
VD4/UniAir-2R 12-17-24 (right lateral operating mechanism; version for UniAir switchgear P1/E 2R unit - IP30
version – unit with circuit-breaker withdrawable on the supply and load side)
1VCD4000981VCD000107
1VCD4000981VCD000107
1VCD4000981VCD000107
1VCD4000981VCD000102
1VCD4000981VCD000102
1VCD4000981VCD000102
1VCD4000981VCD000103
1VCD4000981VCD000103
1VCD4000981VCD000103
