Figure 3/1: Circuit-breaker, operator's side Figure 3/2: Circuit-breaker, terminal side

50.8 Wheel

57.1 Upper terminal

57.2 Lower terminal

57.4 Pole tube caps

57.5 Transport plugs

57.8 Insulating material pole tube

57.5

57.4

57.2

57.8

57.1

50.8

Figure 3/3: Circuit-breaker, version with partition, terminal side
