24
Designation Item Rated supply Ident no.
no. voltage (order code)
Auxiliary switch -S1 GCE7002397R0122
(with clamp-type terminal) -S3 GCE7002397R0121
-S4 GCE7002397R0122
-S5 GCE7002397R01..
1)
Auxiliary switch on blocking magnet -S2 GCE7003022P0101
Auxiliary switch for fault annunciation -S7 GCE0905121P0100
1st shunt release OFF -Y2 GCE7004590P01..
2)
2nd shunt release OFF -Y9 GCE7004590P01..
2)
Shunt release ON -Y3 GCE7004590P01..
2)
Blocking magnet -Y1 GCE9478103P01..
2)
Undervoltage release -Y4 GCE9371466R01..
2)
with spring mechanism
Delayed undervoltage release -Y4 GCE9371466R01..
2)
with spring mechanism
Indirect overcurrent release with intermediate -Y7 GCE9371466R0112
current transformer and spring mechanism
Intermediate current transformer for GCE9476148R0100
indirect overcurrent release
Magnet holder, complete GCE7000880R0111
(with integrated rectifiers -V1, -V2, -V3, -V9)
Series rectifier -V4/-V7 GCE7004046R0101
Charging motor -M0 GCE0940084P....
3)
(with gearing)
1)
Quote contact arrangement
2)
State the type of release and voltage
3)
State rated supply voltage, Serial-Nr. of switch (on
identification sign) as well as the manufacturer of the motor
Ident no.
(order code)
• Lubricants:
– Isoflex Topas NB 52 GCE0007249P0100
• Cleaning agents for general cleaning:
– Rivolta BWR 210 GCE0007707P0100
– Observe the relevant ABB instruction manual BA 1002/E GCEA901002P0102
• Cleaning agent for conductive parts,
insulating-material parts, and all parts with heavy
contamination:
– Cold cleanser 716 GCE0007706P0100
– Observe the relevant instruction manual BA 1006/E GCEA901006P0102
• Touch-up paint:
Standard colour Ral 7035
– 1 kg-box GCE9014060R0103
– Spray tin GCE0007895P0100
7.5.2 Auxiliary materials
24V...240V
Push-on sleeve 4,8-2,5 for push-on blade 0,8 thick DIN 46247 Page 2
(for additionel external connections)
