ABB VD4 Series User Manual

MA_VD4-HD(EN)-_1VCD601410 - 1601 (GS)
ABB S.p.A.
Electrification Products Division
Medium Voltage Products
Via Friuli, 4
I-24044 Dalmine
Tel.: +39 035 6952 111
Fax: +39 035 6952 874
E-mail: info.mv@it.abb.com
ABB AG
Calor Emag Medium Voltage Products
Oberhausener Strasse 33 Petzower Strasse 8
40472 Ratingen 14542 Werder (Havel) OT Glindow
GERMANY GERMANY
Tel.: 02102 12-0
Fax: 02102 12-17 77
E-Mail: powertech@de.abb.com
www.abb.com/mediumvoltage
The data and illustrations are not binding. We reserve the right to modify the
contents of this document without prior notice following technical and product
developments.
© Copyright 2016 ABB. All rights reserved.
Contact us

ABB VD4 Series Specifications

General

Operating mechanism	Spring-operated mechanism
Installation	Fixed or withdrawable
Rated frequency	50/60 Hz
Poles	3
Rated current	Up to 4000 A
Standards	IEC 62271-100
Insulation	Vacuum
Application	Medium voltage
Control voltage	24-240 V AC/DC
Weight	Depending on the specific model
