3 Weight and transportation of the
turbocharger
Lifting gear with a sufficient load limit must be used for installing the turbocharger. The fol-
lowing weight specification applies to the heaviest variant possible. Depending on the spe-
cification, the weight specified on the rating plate may be lower than the standard value
specified here.
Weights of the complete turbocharger
Product Weight [kg]
VTR 184 285
VTR 214 420
VTR 254 675
VTR 304 1100
VTR 354 1800
Table4
