ASM: RASCAL BASE 10-90225
ITEM PART # DESCRIPTION
1 10-10078 LBL: HAND CRUSH: DECAL
2 10-20050 NUT: 1/2-13 HEX FIN: GR 5 ZINC
3 10-20138 1/2" SPLIT LOCKWASHER: ZINC
4 10-20139 HX HD BOLT: 1/2-13 X 4": ZINC GR5
5 10-20141 FLT WSHR: 1/2 SAE: CL ZINC
6 10-20172 HITCH PIN: 5/8" X 5": ZINC
7 10-20194 LYNCH PIN: 1/4" X 1.25": ZINC
8 10-20233 PLATE: RASCAL PIN HITCH
9 10-40043 TUBE: 2" SQ X .25" WALL: RASCAL TONGUE 30" L
10 10-40293 PLATE: RASCAL PIN HITCH
11 10-60006 PLATE: RASCAL PIN HITCH
12 10-60058 PLATE: RASCAL PIN HITCH
13 16-50000 PLATE: RASCAL PIN HITCH
11
12
13
10
8
5
9
1
2
7
3
4
6
