ABI Attachments RASCAL Series - Hitch Tube Assembly

Visit: www.abisupport.com
20
ASM: HITCH TUBE 10-40374
ITEM PART # DESCRIPTION
1 10-10072 2' BALL JOINT COUPLER
2 10-10090 LBL: HAND CRUSH: DECAL
3 10-20138 NUT: 1/2-13 HEX FIN GR 5 ZNC
4 10-20139 1/2" SPLIT LOCKWASHER ZNC
5 10-20141 HX HD BOLT: 1/2-13 X 4": ZINC GR5
6 10-20194 FLT WSHR: 1/2 SAE: CL ZINC
7 10-30048 PLATE: RASCAL PIN HITCH
8 10-50002 PLTUBE:2" SQ X .25" WALL: RASCAL TONGUE 30" L
5
7
6
3
1
4
8
2
Parts Description (cont'd)
