ABI Attachments Workman XL - Unpacking Instructions & Parts List

Visit: www.abisupport.com
8
Tools Needed:
- Gloves
- Safety Glasses
- Safety Shoes
- (2) 10 mm Socket or wrench
- (2) 13 mm (1/2 in) Socket or wrench
- (2) 16 mm (5/8 in) Socket or wrench
- (2) 18 mm Socket or wrench
- 21 mm deep well socket for tires
- Adjustable wrench (optional)
- Standard set of pliers
- Black electrical tape
- Lithium grease
- Razor Blade or knife
- Air Pump
- Wire Crimping Tool
Removing From Shipping Crate
Packing List
Initial Setup Instructions
Hardware Packing List
Unpacking Instruction & Parts
1. Remove lid of box and set out packaged components to
confirm all parts are accounted for (Fig 1),
Workman Bed
Tires (Quantity 4 Deflated)
Set of Struts
Main Frame
Bed Rest
Cross Bar Support
Brake Axle
Idler Axle
Tongue
Optional Tongue Support Bracket
Electric Actuator
Pig skin cover and 2 zip ties
Wiring Harness (2 packs)
A - Subframe Strut Hardware Packet
B - Bed Rest Hardware Packet
C - Black Box Hardware Packet
D - Pivot Mount Hardware Packet
E - Cross Bar Hardware Packet
F - Lower Mount Hardware Packet
G - Upper Mount Hardware Packet
H -Tongue Hardware Packet
H - Axle Hardware Packet
H - Axle Hardware Packet
Packet One: Wiring Harness, Rocker Switch,
Two Extensions (One for Rocker Switch and
One for Main Harness)
Packet Two: Workman to Rascal Adapter
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
PACKET PART # DESCRIPTION QTY
A
Subframe
Strut
Hardware
M8x25 Hex Bolts 16
Washer 32
M8 Nylon Lock Nuts 16
B
Bed Rest
Hardware
M8x70 Hex Bolts 2
Washer 4
M8 Nylon Lock Nuts 2
C
Black Box
Hardware
M6x30 Hex Bolts 4
Washer 8
M6 Nylon Lock Nuts 4
D
Pivot Mount
Hardware
M12x95 Hex Bolts 2
Washer 4
M12 Nylon Lock Nuts 2
E
Cross Bar
Hardware
M10x25 Hex Bolts 4
Washer 8
M10 Nylon Lock Nuts 4
F
Lower Mount
Hardware
M12x75 Hex Bolts 1
Washer 2
M12 Nylon Lock Nuts 1
Spacer 2
G
Upper Mount
Hardware
M12x110 Hex Bolts 1
Washer 2
M12 Nylon Lock Nuts 1
Spacer 2
Tongue
Hardware
M12x80 Hex Bolts 4
M12x30 Hex Bolts 2
Washer 12
M12 Nylon Lock Nuts 6
H
Axle
Hardware
M12x75 Hex Bolts 4
Washer 8
M12 Nylon Lock Nuts 4
H
Axle
Hardware
M12x75 Hex Bolts 4
Washer 8
M12 Nylon Lock Nuts 4
