ChipMaster Compact Digital IC Tester
Copyright 1992-2009 ABI Electronics Limited
Page 9
14. specifications
SPECIFICATIONS
Batteries 4 X AA size
DC input 6V, 850mA max, centre positive, regulated
Power consumption
Power off 10µA max
Standby 30mA
Testing IC dependent
Test thresholds (internal library) TTL low 0.5V max
TTL switching 1.2V
TTL high 2.4V min
CMOS low 0.5V max
CMOS switching 2.4V
CMOS high 3.8V min
Test thresholds (user library) Programmable 0V to 5V (using CompactLink)
RS-232 settings 38400 baud, 8 data bits, 1 stop bit, no parity
Dimensions 200mm X 100mm X 55mm approx.
Library ICs TTL, CMOS, VLSI, Interface, Memory, User
