DELELISTE / DELLISTA / PARTS LIST
DEL NR. / PART NO. BESKRIVELSE / BESKRIVNING / DESCRIPTION ANT. / QTY.
1 Main frame 1
2 Front stabilizer set 95.4*50.6*2.0T*450 1
3 Flat washer D16xD8.5x1.2T 8
4L Left rear foot cap (triangle) 103*68*83 1
4R Right rear foot cap (triangle) 103*68*83 1
5L Left front foot cap (triangle) 123*70*110 1
5R Right front foot cap (triangle) 123*70*110 1
6 Spring washer D15.4xD8.2x2T 22
7 Curved washer D22xD8.5x1.5T 12
8 Buffer D9*D5.8*13 2
9 Allen bolt M8x1.25x20L 20
10 Front post 1
11 Pedal welding set 2
12 Swing support tube 2
13 Bearing #99502ZZ 8
14 Bearing #2203-2RS 2
15 Semi-ball end cap D25.4*31L 2
16 Bearing #99502 2
17 Allen bolt M8x1.25x100L 2
18 Nylon nut M8*1.25*8T 2
19 Rear stabilizer 95.4*50.6*2.0Tx500L 1
20 Carriage bolt M6*1*45L 4
21L Left pedal 420*130*85 1
21R Right pedal 420*130*85 1
22 Adjustable round wheel D59*M10*40L 2
23L Left upper foot cover 80*50*87 2
23R Right upper foot cover 80*55*87 2
24 Anti-loose nut M10*1.25*10T 2
25 Adaptor 26V / 2,5A 1
26 C ring D22.5*D18.5*1.2T 2
27 Computer cable (upper) 900L 1
28 Computer cable (lower) 600L 1
29 Tension control board EMS 7200- AC 1
30 Electric cable 1100L 1
31 Pedal axle D46x44 2
32 Round end cap D45*15 2
33L Left crank 1
33R Right crank 1
34 C ring S-40(1.80T) 2
