Malfunction Messages
1. Operation Feature - Take the connector pin (KEY) of controller as determinant signal, then
converts it into digital codes.
2. Usage Condition - When the controller sends out an error message, (LED) starts ashing
and will display the ‘Error message code’ as follows:
Key On Display
1. Intial Status - When scooter power is on, the back light and all LCD segments will be tuned on
for 3 seconds, then switch to the default working mode automatically.
Warning Tone Setup
1. Operation Feature - The volume of warning tones of Parking light, Reverse, Horn, Low voltage
and Indicator could be adjusted or turned off.
(except you cannot turn off the Horn)
16
Battery needs charging soon.
Low voltage, needs charging now
Over voltage
Over current
Park Brake is lost or faulty
Accelerator Others
Accelerator is broken or faulty
Motor is broken or faulty
Others
Quieter
Quieter
Quieter
Quieter
Loud
