Able Planet LINX AUDIO - Technical Specifications

SYSTEM: INFRARED
CARRIER FREQENCY: LEFT CHANNEL 2.3mHz
RIGHT CHANNEL 2.8mHz
MODULATION Frequency Modulation
INPUT LEVEL 300mV RMS
POWER SUPPLY
TRANSMITTER: 12Vdc, 200mA(AC ADAPTER)
RECEIVER: 2x 1. 5 V UM-4”AAA” Batteries
OUTPUT IMPEDANCE: 40 Ohms
FREQUENCY RESPONSE: 35-18,000Hz
S/N RATIO: 60db
DISTORTION: 0.5% THD
CHANNEL SEPARATION: 45db
SPECIFICATIONS
