Able Planet LINX AUDIO - Installation Guide

1. Connect the stereo signal to the Transmitter with the adapter cord (g. 2)
Note: When batteries are low the LED will not go “ON” and the MUTE FUNCTION
becomes inoperable. Please replace the batteries to restore quality of sound.
2. Insert the supplied AC ADAPTER plug into the INPUT JACK g.1(3) on the back of the
Transmitter. Then plug the ADAPTER module into a standard wall outlet.
3. Place 2-AAA batteries (included) into the battery compartment of the HEADPHONE
as shown in (g.3). Make sure that the battery polarity is correct when inserting
into compartment.
Note: When batteries are low the LED will not go “ON” and the MUTE FUNCTION becomes inoperable.
Please replace the batteries to restore quality of sound.
INSTALLATION
5



  


Power
V
O
L




TRANSMITTER
RECEIVER
MINI PLUG DUAL RCA PLUGS
LEFT RIGHT
Fig.1
Fig.2
Fig.3

Three position tilt base. Transmitter easlly snaps in and out of base.



  


Power
V
O
L




TRANSMITTER
RECEIVER
MINI PLUG DUAL RCA PLUGS
LEFT RIGHT
Fig.1
Fig.2
Fig.3

Three position tilt base. Transmitter easlly snaps in and out of base.
