Abloy EL460 User Manual

12
R
EN 179 EN 1125
EA321, EA322, EA323, EA324, EA325, EA326, EA327, EA328, EA329, EA330, EA331, EA332
100 mm
>1/a
R
Vaselin ISOFLEX TOPAS NB52
F < 70N (7 kg)
Spray
25 mm
F < 80N (8 kg)
>1/a
R
Vaselin ISOFLEX TOPAS NB52
Spray
25mm 25mm
max. 200 kg
L=max. 1320 mm
900 mm - 1100 mm
max. 2520 mm
max. 200 kg
L=max. 1320 mm
l=60%*L
900 mm - 1100 mm
max. 2520 mm
EN 179
ABLOY®
DO 20.33.01
DO 20.33.02
IKON
DO 20.15.01
DO 20.15.02
FSB
DO 20.03.01, DO 20.03.02
HEWI
DO 20.13.01,
DO 20.13.02
SAPEX
DO 20.32.01
DO 20.32.02
10 1001 79, 06 1004 79 RTG/RTV,
10 1004 79, 06 1004 79 RTG/RTV,
10 1016 79, 06 1016 79 RTG/RTV,
10 1023 79, 06 1023 79 RTG/RTV,
10 1035 79, 06 1035 79 RTG/RTV,
10 1045 79, 06 1045 79 RTG/RTV,
10 1070 79, 06 1070 79 RTG/RTV,
10 1078 79, 06 1078 79 RTG/RTV,
10 1093 79, 06 1093 79 RTG/RTV,
10 1107 79, 06 1107 79 RTG/RTV,
10 1108 79, 06 1108 79 RTG/RTV,
10 1119 79, 06 1119 79 RTG/RTV,
10 1146 79, 06 1146 79 RTG/RTV,
10 1159 79, 06 1159 79 RTG/RTV,
10 1160 79, 06 1160 79 RTG/RTV,
10 1163 79, 06 1163 79 RTG/RTV,
10 1189 79, 06 1183 79 RTG,
10 1222 79, 06 1222 79 RTG/RTV
EL460 e.g. ABLOY® INOXI
3-19/013 PZ+BL
e.g. S6B3, S6B6 111, 111.23,
114.23GK,
131, 132, 111X,
113X, 114X, 161X,
163X, 171X, 112X,
165X, 166X
e.g. 60-00819
EL260
EL060
ABLOY® INOXI
3-19/013/120 PZ+BL
e.g. S6B8
ABLOY®
DO 20.33.01
DO 20.33.02
IKON
DO 20.15.01
DO 20.15.02
SAPEX
DO 20.32.01
DO 20.32.02
EL560
EL564
e.g. ABLOY® INOXI
3-19/012 PZ+BL
e.g. S326, S426, S4K3 e.g. 60-0419,
60-0319
EL360
EL160
ABLOY® INOXI
3-19/012/120 PZ+BL
e.g. S4K6
EL165 e.g. ABLOY® INOXI
3-19/012/120 PZ+BL

Abloy EL460 Specifications

General

Operating Temperature	-20°C to +60°C
Bolt Throw	20 mm
Locking Principle	Motorized bolt
Compatibility	Access control systems
Application	Doors
Operating Voltage	12 V DC
Monitored Functions	Bolt position, door position
Suitable for	Fire doors
