Abloy EL460 User Manual

8
R
25 mm
7 x 7 mm/
8 x 8 mm/
9 x 9 mm
50 mm
10 mm
20 mm
8 x 8 mm/
9 x 9 mm
55/60/65/80/100 mm
20/24 mm
10 mm
20 mm
EA218 (6 m) /
EA219 (10 m)
18 x 0.14 mm2
EA218 (6 m) /
EA219 (10 m)
18 x 0.14 mm2
EL560 EL564, EL565, EL165
A
A
EL466 - EL469
EL566 - EL569, MP564, MP565
20 mm
9 x 9 mm
8 x 8 mm /
24 mm
30 / 35 / 40 / 45 mm
1760 / 2000 mm
10 mm
24 / 28 mm
A
B
B
EA218 (6 m) /
EA219 (10 m)
18 x 0.14 mm2
10 mm
1760 / 2000 mm
20 mm
20 / 24 mm
55 / 60 / 65 / 80 / 100
50 mm (MP564, MP565)
9 x 9 mm
7 x 7 mm
(MP564, MP565)
8 x 8 mm /
24 mm
A
B
B
EA218 (6m) /
EA219 (10)
18 x 0.14 mm2

Abloy EL460 Specifications

General

Operating Temperature	-20°C to +60°C
Bolt Throw	20 mm
Locking Principle	Motorized bolt
Compatibility	Access control systems
Application	Doors
Operating Voltage	12 V DC
Monitored Functions	Bolt position, door position
Suitable for	Fire doors
