14
TECHNICAL DATA
Operating voltage: 12 (-10%) 24 (+15%) V DC STAB
Current: Max. 0.35 A
Idle 0.12 A
Micro switches: Max. 0.4 A 30 V AC/V DC resist, 10 W
Ambient temperature: -20° - +60° C
Bolt throw: 14 mm
Backset: 29 mm, 35 mm
Forend: 25 mm
Spindle: 8 mm
Split spindle (EL480): 50 mm (EA288 000000)
Also available 70 mm split spindle (EA288 000010)
Functions selected on the lock case:
Mechanical functions
-handing of trigger bolt and latch bolt
-exit handle side (EL480)
Electrical function
-fail locked / fail unlocked
Lock can always be opened by exit handle (EL480).
Monitoring outputs: -deadlocking status of latch bolt
-indication of handle use
Door clearance: 2,5 5,5 mm (between forend and strike plate)
Connection cable: EA210 (6m), EA220 (10m) 16 x 0.14 mm
2
Strike plate: 4613, 4614
The lock case is recommended to be used with handles with returning springs.
ENGLISH
