Absco 30302GK - COMPONENTS PACKING LIST; Component Identification

COMPONENTS PACKING LIST - CHECK OFF ALL COMPONENTS
PAGE 3
ABSCO INDUSTRIES ASSEMBLY INSTRUCTION - MODEL: 30302GK 27/04/16
Premier Garden Shed -
Model: 30302GK
STEEL SHEET
1785mm X 773mm
30A
2
STEEL SHEET
1785mm X 773mm
31A
2
STEEL SHEET
1915mm X 773mm
36L
2
STEEL SHEET
1915mm X 773mm
36R
2
90A
JAMB L= 1568mm
1
91A
JAMB L= 1120mm
4
87A
LIP TRIM L= 1546mm
4
15A
2
PEAK BRACE
2
CHANNEL
L = 1518mm
84L
58B
1
CHANNEL
L = 1725mm
58A
2
CHANNEL WITH HINGES
L = 1725mm
97A
1
RIDGE
BEAM
L = 2993mm
COMPONENT
DESCRIPTION
PART
No.
CHECK
COMPONENT
DESCRIPTION
PART
No.
CHECK
QTY QTY
STEEL SHEET
1785mm X 711mm
34A
2
STEEL SHEET
1725mm X 773mm
A
1
89C
JAMB L= 1725mm
1
89A
JAMB L= 1785mm
2
STEEL SHEET
2045mm X 773mm
38R
2
STEEL SHEET
1546mm X 773mm
45A
8
STEEL SHEET
2045mm X 773mm
38L
2
STEEL SHEET
1725mm X 773mm
B
1
