Absco 30302GK - FITTINGS PACKET CONTENTS; Hardware Identification

PAGE 4
ABSCO INDUSTRIES ASSEMBLY INSTRUCTION - MODEL: 30302GK 27/04/16
Premier Garden Shed -
Model: 30302GK
58C
4
CHANNEL
L = 773mm
2
CHANNEL
L = 1518mm
84R
79A
1
CHANNEL
L = 1568mm
14A
2
CAP GABLE
L: 170mm
12
4mm CSK SCREW &
NUT SECURE HINGES
TO DOOR
8
4mm NUT & BOLT SET
SECURE TWO
PADBOLTS TO DOOR
SHEET
220
SELF TAPPING
SCREWS
3
DOOR
PADBOLT
2
DOOR
PADBOLT
HASP
12
3mm POP RIVETS SECURE
HINGES TO DOOR
(ALTERNATIVE FIXING
METHOD)
1
ASSEMBLY
INSTRUCTIONS
COMPONENT
DESCRIPTION
PART
No.
CHECK
COMPONENT
DESCRIPTION
PART
No.
CHECK
QTY QTY
CONTENTS OF FITTINGS PACKET
COMPONENTS PACKING LIST - (CONT.) CHECK OFF ALL COMPONENTS
12A
2
DOOR
STRAP
L: 165mm
22A
8
1 1
SELF DRILLING HEX
HEAD TEK SCREWS (NO
HOLE REQUIRED)
3mm (0.12") DRILL BIT
HEX TEK SCREW
DRIVER BIT
