ABSCO INDUSTRIES ASSEMBLY INSTRUCTION - MODEL: 30302GK 27/04/16
Premier Garden Shed -
Model: 30302GK
COMPONENTS PACKING LIST - (CONT.) CHECK OFF ALL COMPONENTS
55AL
55CL
55BL
81BL
81AL
60AL
97AL
55CR
1
1
1
1
4
2
1
RIDGE
BEAM
THESE COMPONENTS
ARE TO BE
JOINED
TO THESE COMPONENTS
1
1
1
1
4
2
1
CHANNEL
L = 1496.5mm (58.9")
CHANNEL
L = 1496.5mm (58.9")
CHANNEL
L = 1496.5mm (58.9")
CHANNEL
L = 1496.5mm (58.9")
CHANNEL
L = 1496.5mm (58.9")
CHANNEL
L = 1496.5mm (58.9")
L = 1521mm (59.9")
55BR
81BR
81AR
60AR
97AR
55AR
CHANNEL
L = 1496.5mm (58.9")
CHANNEL
L = 1496.5mm (58.9")
CHANNEL
L = 1496.5mm (58.9")
CHANNEL
L = 1496.5mm (58.9")
CHANNEL
L = 1496.5mm (58.9")
CHANNEL
L = 1496.5mm (58.9")
RIDGE
BEAM
L = 1521mm (59.9")
COMPONENT
DESCRIPTION
PART
No.
CHECK
COMPONENT
DESCRIPTION
PART
No.
CHECK
QTY
CSJ
QTY
10
ZARSP
1
CHANNEL JOINER
L= 200mm (7.9")
RIDGE BEAM JOINER
L: 450mm (17.7")
