REPLACING THE ELECTROMAGNET
g the
Electromagnet
S
S
T
T
E
E
P
P
4
4
FITTING THE ELECTROMAGNET
Mount
new the electromagnets in the
unit.
Tighten up nuts with nut driver.
S
S
T
T
E
E
P
P
5
5
Install the SP switch to the frame with the screws.
●Be careful of the direction of switch lever. (Refer to
the
pictures)
S
S
T
T
E
E
P
P
6
6
Insert the wire into the silicon tube, and tie up in
a
bundle.
Strip the coating off each
wire.
(5-7mm from the
end)
Connect the wires to the
terminals.
Solder the wires to the
terminals.
The wire requires a soldered
connection.
S
S
T
T
E
E
P
P
7
7
This completes the
electromagnet replacement
procedure.
