Abus PPIC90000 User Manual

5
Tecla Reset
Reset button
Tecla de emparejamiento
Pairing button
Para la grabación, es necesaria una tarjeta Micro SD (máx. 128 GB de capacidad de
memoria). Para introducir y extraer la tarjeta SD, es necesario desconectar la unidad
base de la interfaz USB. Al introducirla, la tarjeta SD encaja de forma audible.
Para la extracción, se incluye una herramienta de extracción.
A standard micro USB card (max. 128GB storage capacity) is required for recording.
Thebasestation must be disconnected from the USB interface in order to insert
and remove theSDcard. The SD card audibly snaps into place when fully inserted.
The provided removal aid can be used to remove the card.
UNIDAD BASE
MAIN UNIT
Ranura para tarjeta microSD (máx. 128 GB)
Micro SD card slot (max. 128GB)
LED de estado
Status LED
Tarjeta Micro SD opcional
Optional micro SD card
Herramienta
de extracción
Removal aid

Abus PPIC90000 Specifications

General

Type	IP security camera
Placement supported	Indoor & outdoor
Connectivity technology	Wireless
Form factor	-
Mounting type	Wall
Product color	Black, White
Housing material	Plastic
International Protection (IP) code	IP65
Camera pan control	No
Minimum illumination	1 lx
Field of view (FOV) angle	115 °
Number of sensors	1
Fixed focal length	2.9 mm
Total megapixels	2 MP
Maximum resolution	1920 x 1080 pixels
Video formats supported	H.264
Number of users	3 user(s)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	128 GB
Power source type	Battery, DC
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	51 mm
Width	103 mm
Height	54 mm
