5 Control unit
Point Description
1
The LED lights constantly if the there is a
fault in the telephone line.
2
The LED lights constantly if the system
has a fault and must be checked.
3
The LED lights constantly if the power
supply is present and working. The LED
flashes if the power supply fails and the alarm
system is being operated by the battery.
4 These buttons activate the alarm system in
the different areas.
5 LCD control unit plain-text display
6 This button confirms input.
7 This button cancels input and calls the
blocking user function.
8 This buttons opens the front cover.
Additional buttons (see programming menu “87
Control Unit Alarm”):
1 & 3: Press simultaneously to trigger a panic alarm on
the control unit.
4 & 6: Press simultaneously to trigger a medical
emergency alarm on the control unit.
7 & 9: Press simultaneously to trigger a fire alarm on the
control unit.
