Abus TV7180 - Technical Data

17
8. Technical data
Model number
TV7180 TV7181
Image sensor
1/3 interline transfer CCD ¼ SONY Super HDD
CCD
TV lines / pixels 400TVL /291000 330TVL / 291000
Minimum illumination 0,3 Lux bei F2.0 0.5 Lux bei F2.0
Signal-to-noise ratio >48dB
AES 1/50s ~1/110000s
Synchronisation intern
Lens 3,6mm / F2.0 / miniature lens
Video out 1Vss /75Ohm/ BNC- connector
Power source 12 VDC
Power consumption 1,32W (110mA) 1,44W(120mA)
Video norm CCIR PAL
Dimensions / Weight Ø28 x 89,5mm / max. 172g
Operating temperature -10° C - +50° C
Operating humidity 100% waterproof
Protection type IP66
