Abus TVAC18010A - 8 Technical Data

24
English
8. Technical data
Model number
TVAC18010A
Frequency
2.4 GHz
Modulation
GFSK
Transmission power
15 +/- 2 dBm
Sensitivity
-80 dBm
Image sensor
1/4" CMOS
Resolution
640 × 480 pixel (VGA)
No. of IR LEDs
6 IR LEDs
Lens
3.6 mm
Angle of view
60° (H)/43° (V)
Night vision function range
5-8 m
IR swivel filter
Yes
IP protection class
IP66
Wireless range
approx. 100 m (clear sight line)*
Power supply
5 V DC/1 A
Power consumption
Max. 550 mA
Operating temperature
-10 °C–50 °C
Dimensions (L × W × H)
150 × 74 × 68 (without antenna and mount)
Weight
390 g
* The range depends on the ambient conditions (e.g. mobile phone masts, high-tension electricity pylons,
power lines, ceiling and walls, etc.).
If the conditions are unfavourable, the range may be very restricted.
