Features
• Universal data converter makes your serial terminal network-ready
• Supports the most common serial interfaces RS232, RS422 and RS485
• Supports data baud rade 1200 to 115200 bps
• Supports auto MDI / MDIX
• Supports three operation modes TCP Server, TCP Client and UDP Mode
Specification
LED
LED
Color
Status
Description
Power
LED
Green
Off
Device off / no power supply
On
Device on (in operation mode)
RX
Blue
Blink
Data receiving
TX
Blue
Blink
Data transmitting
Item #
TVAC23000
Dimensions
67 x 110 x 27 mm
Connections
1 x RJ45, 1 x RS232 (DB9 male), 1 x RS485/RS422
(4-pin)
Functions
TCP Server, TCP Client, UDP Mode
Housing material
Aluminum
Scope of delivery
Interface converter (RS232/RS485/RS422 -> TCP/IP),
power supply, mounting material
Max. humidity
95 %
Max. operating temperature
70 °C
Min. operating temperature
0 °C
Net weight
0,18 kg
Voltage supply
5 V DC
Power consumption
600 mA
