Abus TVAC71000 - Technical Data

26
English
9. Technical data
Model
TVAC71000
TVAC71010
TVAC71020
TVAC71030
TVAC71040
IP protection class
IP 66
IP 66
IP 66
IP 66
IP 66
Dimensions
85 x 55 x 49
85 x 55 x 49
85 x 55 x 49
85 x 55 x 49
134 x 67 x 64
Weight
0.35 kg
0.35 kg
0.35 kg
0.35 kg
0.6 kg
IR wavelength/
Colour temperature
850 nm
850 nm
940 nm
940 nm
6300 K
Voltage
12–24 VDC/VAC
12–24 VDC/VAC
12–24 VDC/VAC
12–24 VDC/VAC
12–24 VDC/VAC
Current
0.5 A max.
0.5 A max
0.5 A max
0.5 A max
1 A max.
Operating
temperature
-30 … +40 °С
-30 … +40 °С
-30 … +40 °С
-30 … +40 °С
-30 … +40 °С
Range
at 0.1 Lux
10 m
20 m
5 m
10 m
18 m
Angle of view
60°
30°
60°
20°
60/40
IR activation
< 3 lux
< 3 lux
< 3 lux
< 3 lux
< 3 lux
Housing material
Aluminium
Aluminium
Aluminium
Aluminium
Aluminium
