24
English
4. OSD menu
The camera's on-screen display (OSD) can only be opened by devices with control capabilities
(recorder, control panel). To open the OSD menu, either use the “Iris+” option or call up preset 95. To
navigate, use the device's PTZ arrow keys and the “Iris+” option to open and confirm.
The OSD menu is only available in English. Please familiarise yourself with the description
of the points below.
The “Iris+” option may differ for each device.
MAIN MENU
General menu navigation
BACK Go back one menu step
EXIT Leave main menu without saving changes
EXIT & SAVE Leave main menu and save all changes
VIDEO FORMAT Select video format
EXPOSURE
EXPOSURE MODE Set exposure mode
• GLOBAL Automatic
• BLC Backlight compensation
• HLC Highlight compensation
• WDR Wide dynamic range
AGC Automatic gain control
• OFF Off
• LOW Low
• MIDDLE Middle
• HIGH High
SLOW Low shutter speed
• OFF Standard shutter speed
• X2 – X16 High shutter speed
DAY NIGHT
MODE Set mode
• AUTO Automatic
• COLOR Image is always in colour
• BW Image is always in black/white
IR LIGHT Enable/disable IR light
SMART IR Set smart IR mode
• MODE 1 For indoor/outdoor
• MODE 2 For indoor
• MODE 3 For outdoor
LEVEL Select IR level
D->N THRESHOLD Day to night threshold
• The lower the value, the sooner the camera switches between
day/night mode
• The higher the value, the later the camera switches between
day/night mode
N->D THRESHOLD Night to day threshold (see above)
