English
10. Then fasten the adapter using the grub screw to help you.
11. Hang the Speed Dome into the mount using the fastening hook to help you. Then guide the cable
through the mount.
12. Align the label on the adapter with the Speed Dome. Then tighten the housing by turning it clockwise.
Secure the adapter using the two fastening screws to help you.
2
1
Adapter
Fastening screw
Adapter seen from above
