5. Device description
5.1 Overview – model number
Item number TVHD40000
Resolution 1080p / 2.0 MPx
Lens 4.0 mm
IR

IR swivel filter
(ICR)

Operating voltage 12 VDC
5.2 Unpacking the device
Handle the device with extreme care when unpacking it.
If the original packaging has been damaged, inspect the device. If the device shows signs
of damage, then return it in the original packaging and contact the delivery service.
5.3 Camera description
(1) Camera
(2) Sunshield
(3) Camera mount
(4) Connection cable
(5) Connection for video signal (BNC)
(6) Connection for power supply
(circular connector, 5.5 x 2.1 mm)
(7) WDR control
(8) IR LED control
1
2
3
4
5
6
8
7
