8. OSD Menu
Function Description
QUICK INSTALL Quick setup of the most important camera parameters
ADVANCED MENU Detailed explanation of all camera parameters
EXIT Exit menu
QUICK INSTALL
The "QUICK INSTALL" function has been implemented for simple configuration of the
camera. This function takes you through the most important menu items in order to quickly
adjust the camera to the given lighting conditions.
Press "Enter" on the back of the camera to open the camera's "MAIN MENU". Use the
buttons described in the last section to open the "QUICK INSTALL" menu and select the
desired settings.
MAIN MENU
QUICK INSTALL
ADVANCED MENU
EXIT
The "QUICK INSTALL" menu contains the following steps:
A description of the different steps can be found in the following table.
To get to the next step in the "QUICK INSTALL" menu, select "NEXT" in the display.
"BACK" brings you to the previous step.
Quick
Install
EXPOSURE SHUTTER WDR
WHITE
BALANCE
END
If the desired settings do not result in optimal image performance, you can
perform "QUICK INSTALL" again at any time and adjust the settings.
