22 23
+
-
+
+
-
-
x = 0 - 7 mm -----
x = 8 - 12 mm 7 mm
x = 13 - 16 mm 14 mm
x = 17 - 30 mm 7 + 14 mm
x*
4.1 b
4.1 c
Position magnet
holder and bases
(Attention: do not
fasten yet!)
14 mm
7
mm
4.1 d
press
tone sounds.
Mark the position of the holder
If the signal does not sound, the
position was not detected. Check
the position of the holder and the
number of supports, or rotate the
magnets by 180°!
1.
2.
3.
4.1 e
Screw on the base(s), magnet holder moun-
ting and screws according to the table in
4.1b at the marked position.
Press down on the magnet holder.
5.
Battery replacement
5.25.1
4.1 g4.1 f
ca.
9 cm
max.
1 cm
