24 25
5.45.3
5.65.5
5.85.7
+
-
+
+
-
-
+
-
+
+
-
-
+
-
+
+
-
-
+
-
+
+
-
-
- The drive cannot be programmed, there is no acknowledgement tone
=> drive plate on back of housing is not set correctly (go to 2.2f)
- It is not possible to move to zero position (handle in closed position)
- When opening the window / patio door from its tilt position, and it falls out
of its anchoring
=> Deactivate tilt function or support door during motorised movement (Set
the tilt function in the app)
- During the motorised movement, a warning signal sounds, the drive jams
drive)
=> Check ease of movement of the window / patio door and adjust as
necessary
=> Increase drive torque if necessary (Set the torque in the app)
in the pressure cylinder
=> “Low batt” message, replace all batteries with new alkaline batteries or
fully charged “ready-to-use” batteries (go to Battery replacement)
2 seconds
=> The window handle is not in closed position
=> Check the magnet position
- The handle cannot be operated mechanically
=> Cylinder pushed in, unlock with key
Check WINTECTO One for damage at least once a year. If the product
shows visible damage, it must no longer be used.
Clean WINTECTO One only with a damp cloth, do not use aggressive
cleaning agents.
6.
7.
Tecnical data
Dimensions (incl. handle) 62 x 300 x 92 mm
Weight (without batteries) 1441 grams
Battery type
Operating temperature range 0°C to +40°C
Max. radiated transmission power < 10dBm eirp
Encryption AES-128-Bit
