12
INSTALLATION
IONBEAM LED LIGHT BARS
STEP 1
Assemble the light bar chain.
Connect the single-corded LED light bar's
female port to the dual-corded LED light
bar's male connector.
Connect the light controller's male
connector to the other end of the dual-
corded LED light bar.
Connect the power adapter to the
light controller.
A
B
C
A.
Secure all connections using the twist-on pieces.
B.
C.
Included in AC-HDL5, AC-HMX5, AC-HDL7, and AC-HMX7 models.
