INSTALLATION
STEP 1
Locate the connector plug of the sensor probe
and plug it into the sensor port at the bottom
side of the controller.
STEP 2
Position the corded sensor probe and secure
it by using the included zip ties and tie mounts
if needed.
The probe can be placed inside a humidity
dome seedling tray to monitor the current levels.
*Do not allow the probe to be submerged in
water.
T-SERIES MODELS
