5 VITAL Installation and User Guide
INSTALLATION
CONNECTION DIAGRAM
Pin
Input
Function
Color
Bag Tug,
Push Backs,
Hi-Speeds*
Belt
Loader*
De-Icers,
Towbarless*
Others
where
productive
inputs are
not available
1
DC, IN
RED
BATT +
BATT +
BATT +
BATT +
2
Key
GREEN
IGNITION
IGNITION
IGNITION/
FRONT &
REAR ENGINE
(May need a
Diode
Assembly)
IGNITION
3
Seat
BLUE
SEAT OR
IGNITION
SEAT OR
IGNITION
FRONT
ENGINE
SEAT OR
IGNITION
4
Travel**
WHITE
TRACTION
OR
NEUTRAL
BELT
(May need a
Diode
Assembly)
CRADLE OR
NEUTRAL
N/C
5
Aux**
BROWN
N/C
N/C
REAR ENGINE
N/C
6
DC, GND
BLACK
BATT -
BATT -
BATT -
BATT -
* Typical GSE installation, may differ per application.
**If access to these inputs is not feasible, please order non-invasive current sensor part no. HACC-CS.
