Quick Installation Guide
7
7
Product Specifications
Base Unit
Physical Characteristics
Access Method CSMA/CD, 10 Mbps or 100 Mbps
Standards Conformance IEEE 802.3, IEEE 802.3u
Communication Rate 10/100 Mbps
Communication Mode Full or half duplex
Media Supported 10BASE-T - 100WCategory 3,4,5 twisted-pair
100BASE-TX - 100WCategory 5 twisted-pair
Indicator Panel Power, link/activity, speed (100 Mbps), full duplex (FDX)
Number of Ports ES3008A ES3016A
10BASE-T/100BASE-TX 8 RJ-45 ports 16 RJ-45 ports
MDI-X/MDI Selection
1
Alternate ports Toggle switch 1: on last port
Dimensions 251x118x37 mm 330x204x44 mm
(9.9x4.7x1.5 in) (13x8x1.7 in)
Weight 0.8Kg (1.76lb) 2.1Kg (4.63lb)
Power Consumption 20 Watts max. 27 Watts max.
Heat Dissipation 68 BTU/hr max. 92 BTU/hr max.
Maximum Current (@110/240V) 0.2 / 0.1 ARMS 0.5 / 0.22 ARMS
Input Power 100 to 240V (±10%), 110 to 230V (±10%),
50 to 60 Hz (±3Hz), 47 to 63 Hz (±3Hz)
Temperature Standard Operating: 0 to 50°C (32 to 122°F)
Storage: -40 to 70°C (-40 to 158°F)
Humidity 5% to 95% (Noncondensing)
Certification CE Mark
Emissions FCC Class B, VCCI Class B, CISPR Class B
Immunity IEC 1000-4-2/3/4/6
Safety CSA/NRTL (C22.2.950,UL1950), TÜV/GS
(EN60950)
Switching Criteria
Network Bridging Function Filtering, forwarding and learning
Switching Method Store-and-forward
Address Table ES3008A: 1K entries
ES3016A: 8K entries
Address Resolution Via fast hashing scheme
Filtering/Forwarding Rate Line speed
Traffic Control
Flow Control Back pressure for half-duplex
IEEE802.3x for full-duplex
