MISCELLANEOUS
(本体その他使用部品)
No.
T001
Packing
Material
梱包材
Description(部品名)
PC Board for
Power Supply Ass'y
Display Ass'y
Display Ass'y
Display Ass'y
Display(A) Ass'y
Display(B) Ass'y
DAC Ass'y
Traverse/光学ﾄﾞﾗｲﾌﾞﾕﾆｯﾄ
Switch Ass'y /ｽｲｯﾁAss'y
Motor Ass'y /ﾓｰﾀ Ass'y
Motor/ ﾓｰﾀ
Belt / 角ﾍﾞﾙﾄ
Fuse T315mA L 250V
ﾌｭｰｽﾞ T160mA L 250V
Power Transformer / ﾊﾟﾜｰﾄﾗﾝｽ
Outer Carton Box(外ﾀﾞﾝﾎﾞｰﾙ箱)
Inner Carton Box(内ﾀﾞﾝﾎﾞｰﾙ箱)
Top Pad (Front)
ﾄｯﾌﾟﾊﾟｯﾄﾞF
Top Pad (Rear)
ﾄｯﾌﾟﾊﾟｯﾄﾞR
Bottom Pad (Front)
ﾎﾞﾄﾑﾊﾟｯﾄﾞF
Bottom Pad (Rear)
ﾎﾞﾄﾑﾊﾟｯﾄﾞR
Top Board /天地当板
Cover /保護ｶﾊﾞ
Caution Tag/注意銘板 (保護ｽﾍﾟｰｻ)
Accessories Case /付属品ｹｰｽ
Wrapping Sheet /付属品ｹｰｽ用ｼｰﾄ
Bag for AC Cord/保護ｶﾊﾞ
Bag for Remote /保護ｶﾊﾞ
Poly Bag /ﾋﾞﾆｰﾙ袋 for Manual
Poly Bag /ﾋﾞﾆｰﾙ袋 for Battery
Part No.
115-2671-00
115-2667-00
115-2672-00
115-2673-00
115-2668-00
115-2669-00
115-2666-10
733-0001-00
726-0277-00
726-0276-00
224-0001-00
214-0001-00
310-1032-00
310-1013-00
510-4049-10
800-0346-04
801-0172-04
803-0328-10
803-0329-10
803-0401-00
803-0331-10
803-0033-14
810-4843-04
180-2043-14
801-0287-00
810-4545-04
810-2030-04
810-0930-04
812-2435-04
812-0507-00
Remarks
INPUT
OPNE/CLOSE
for 100-120V
for 220-240V
(前)
(後)
(前)
(後)
(本体用)
ﾄﾚｨﾊﾟﾈﾙ用
ACｺｰﾄﾞ
ﾘﾓｺﾝ
取説用
電池用
No.
Screws
for
ﾈｼﾞ類
Description(部品名)
Front Panel /ﾌﾛﾝﾄﾊﾟﾈﾙ用ﾈｼﾞ
Binding Screw /ﾊﾞｲﾝﾄﾞﾂﾒﾂｷBﾀｲﾄﾈｼﾞ
Panel End Cap/ﾊﾟﾈﾙｴﾝﾄﾞｷｬｯﾌﾟ
Pan Head ISO Metric Screw
ﾊﾞｲﾝﾄﾞ平ﾜｯｼｬ付きﾈｼﾞ
Top Plate Ass'y /ﾄｯﾌﾟﾌﾟﾚｰﾄ
Binding Screw /ﾌﾞﾚｻﾞｰﾂﾒﾂｷBﾀｲﾄﾈｼﾞ
Binding Neil Screw
ﾊﾞｲﾝﾄﾞﾂﾒﾂｷBﾀｲﾄﾈｼﾞ
Side Plate/ｻｲﾄﾞﾌﾟﾚｰﾄ
Brazier Head Screw/ﾊﾞｲﾝﾄﾞﾈｼﾞ
Binding Screw/ﾊﾞｲﾝﾄﾞﾈｼﾞBﾀｲﾄﾈｼﾞ
Washer/平ﾜｯｼｬ
Bottom Plate /ﾎﾞﾄﾑﾌﾟﾚｰﾄ
Binding Screw/ﾊﾞｲﾝﾄﾞﾂﾒ付Bﾀｲﾄﾈｼﾞ
Leg / 脚用
Binding Screw /ﾌﾞﾚｻﾞｰBﾀｲﾄﾈｼﾞ
Power Transforer/ﾊﾟﾜｰﾄﾗﾝｽ用
Binding Screw /ﾌﾞﾚｻﾞｰBﾀｲﾄﾈｼﾞ
Owner's Manual(多ヶ国語)
取扱説明書 ERP(Eco/ｴｺﾓｰﾄﾞ）
取扱説明書 (日本語)
Notes (多ヶ国語)
注意書(日本語)
USB Utilities Setup Guide
USBﾕｰﾃｨﾘﾃｨｾｯﾄｱｯﾌﾟｶﾞｲﾄﾞ
目隠しｼｰﾙ/ｽﾃｯｶ
案内状
USB Utility CD /USBﾕｰﾃｨﾘﾃｨCD
Power Supply Cord (J type)
電源ｺｰﾄﾞ (U,T type)
(E type)
(C type)
Remote Commander/ﾘﾓｰﾄｺﾏﾝﾀﾞ
Battery / 電池
Audio Cord Set/ ｵｰﾃﾞｨｵｺｰﾄﾞ ｾｯﾄ
Pin Jack Cover / ﾋﾟﾝｼﾞｬｯｸｶﾊﾞ
Connector Cover for male/ｺﾈｸﾀｶﾊﾞ
USB Dust Cover/USBﾀﾞｽﾄｶﾊﾞ
Part No.
61B-0308-04
631-0044-10
616-0306-02
631-0054-00
604-0408-00
614-0308-00
637-0042-07
631-0054-00
611-0414-02
611-0408-02
820-3312-10
820-4312-10
820-0312-10
821-0011-00
821-0010-00
820-3300-10
820-0300-10
180-9230-00
859-1011-00
783-0005-00
680-1406-10
680-2403-00
680-3403-00
680-5402-00
729-0130-00
569-0008-00
686-0025-00
254-2015-04
254-2027-04
254-2038-00
Remarks
3×8mm 6pcs.
3×6mm 4pcs.
3×6mm 6pcs.
2pcs.
M3×6 4pcs.
4pcs.
4pcs.
3×10mm 17pcs.
4×14mm 4pcs.
2pcs.
Multi-lingual
E type only
Japanese
Multi-lingual
Japanese
Multi-lingual
Japanese
国内のみ
国内のみ
2-conductor
2-conductor
3-conductor
RC-130
LR6 単3型
L/R ２本組
4pcs.
2pcs./出力用
USB用
Accessories
付属品
－ ６ －
REPEAT button
INPUT selector button
PLAY button
FR-/FF+ button (長押し)
STOP button
Direct play button
TIME button
PAUSE button
VOLUME Control
Battery
/
LR6
電池/単三
(569-0008-00)
The button key ofa
gray character can
be used with Pre amp・
Integrated amp of our
products.
ｸﾞﾚｰ文字のﾎﾞﾀﾝｷｰは
当社 のﾌﾟﾘ・ﾌﾟﾘﾒｲﾝ
ｱﾝﾌﾟで使用するこ と
がで き ます。
LEVEL Volume button
BACK-/NEXT+ :track search
OPEN/CLOSE button
＋
－
Battery Case
Assembly
電池ｹｰｽAss'y
(249-0046-02A)
Screw
ﾈｼﾞ/4pcs.
(631-0106-00)
Spacer
ｽﾍﾟｰｻ/2pcs.
(250-1392-04)
