Figure 1
3.2 Recommended Tools
● Phillips screwdriver
● Compass or GPS (for wind direction calibration)
● Adjustable spanner
● Hammer and nail for hanging remote thermo-hygrometer transmitter.
3.3 Sensor Assembly Set Up
Figure 2 shows the sensors included in the Integrated Outdoor Transmitter.
Figure 2
Insert batteries into the transmitter. Locate the battery door on the transmitter, push and open the battery
compartment, as show in Figure 3.
