AccuRelief ACRL-3000 - Dual Channel Electrode Placement; Dual Channel Placement Guide

20
NECK / CERVICAL PAIN
Attach both sets of pads on
the neck. (Do not place on the
carotid artery or throat.)
SHOULDER PAIN
Attach one set of pads in front
and one set in back of the
muscle.
CARPAL TUNNEL /
HAND PAIN
Attach both sets of pads on the
hand where you feel pain.
LOWER BACK /
LUMBAR PAIN
Attach both sets of pads on the
lower back with the backbone in
the center. Do not place on the
backbone or spine.
ELBOW PAIN
Attach both sets of pads on
either side of the joint with
the pain.
UPPER ARM PAIN
Attach both sets of pads on
either side of the region where
you feel pain.
Dual Channel Electrode Placement
The AccuRelief™ Dual Channel TENS unit features one or two channels for pain relief. When using two
channels and two sets of electrodes, use the following placement guide:
Top
of
hand
Palm
