Accurion Halcyonics Vario Basic Series - System Dimensions; Transmissibility of Vario Basic System

Dimensions of the System
Fig. 6: Dimensions of the Halcyonics Vario Basic 40/60/90 systems
Transmissibility of the Vario Basic System
Fig. 7: Transmission graph of Vario Basic 40-100 measured at a velocity
of 100 µm/s with a payload of 50 kg (110 lbs)
450 mm
17.7 in.
135 mm
5.3 in.
345 mm
13.6 in.
4 port control unit
Vario Basic 60 and 90
84 mm
3.3 in.
130 mm
5.1 in.
Vario Basic 60 636 mm
25 in.
Vario Basic 90 932 mm
36.7 in.
111 mm
4.4 in.
237 mm
9.3 in.
345 mm
13.6 in.
135 mm
5.3 in.
2 port control unit
Vario Basic 40
84 mm
3.3 in.
120 mm
4.7 in.
Vario Basic 40 396 mm
15.6 in.
111 mm
4.4 in.
0,010
0,100
1,000
10,000
0,1 1,0 10,0 100,0
Transmissibility
Frequency [Hz]
Halcyonics Vario Basic 40-100
vertical
- 12 -
237 mm
9.3 in.
135 mm
5.3 in.
345 mm
13.6 in.
345 mm
13.6 in.
135 mm
5.3 in.
450 mm
17.7 in.
