I. PC UPRIGHT UNITS (For Portable & Central Systems)
60%
%
-7-
-
6-
-5-
-4-
-3-
-2-
-1-
N
2
O
O
2
Flush
U
L
T
R
A
PC
N O
2
-
7-
-
8-
-9-
-10-
-6-
-5-
-4-
-3-
-2-
-1-
O
2
Off
F
L
O
W
+
-
13"
5"
8"
TECHNICAL SPECIFICATIONS
Physical 5" x 13" x 8" (12, 7 x 33 x 20, 3 cm)
Weight 5.1 lbs (2, 3 kg)
Bottom mount: 1/2 – 20 Thread
Top Mount: 3/4 Diameter Hole
Gas Supply
Oxygen: 50-55 PSI at 100 LPM
N
2
O: 50-55 PSI at 10 LPM
Gas Fittings
Oxygen Inlet: Male DISS (CGA 124)
N
2
O Inlet: Male DISS (CGA 1040)
Mixed Gas Outlet: O.D. .875
" (2, 2)
Oxygen Resuscitator: 1/4" I.D. Quick Disconnect
Gas Delivery
Oxygen Flush: Min 20 LPM
Oxygen Flow: 1 - 10 LPM (Accuracy, +/- 0.5 LPM)
Oxygen Resuscitator : Min 100 LPM 100% O
2
Nitrous Oxide Flow: 0 - 7 LPM (Accuracy +/- 0.5 LPM)
Nitrous Oxide %: 0-70%*
*50% Max Units Available
Outspout
Total Flow
Knob
Oxygen
Flush
Nitrous Oxide
Flow Tube
Oxygen
Flow Tube
%
N
2
O Knob
Top
Mounting Bracket
(3/4" Ø)
Serial #
Oxygen
Resuscitator
Connection
O
2
Inlet DISS
N
2
O Inlet
DISS
Bottom Mount
Threads 1/2 – 20
Room Air Override
Downspout
