ACDelco ARM601-3 - Controls and Display Elements; Technical Specifications

1English1
English -7
11. Torque Value Display 12.Measuring Units.(*1)
13. Power/Reset Button 14. Up Button
15. Down Button 16. Unit/Torque Setting Button
17. Modes Select(*2)
EXPOSITION:
:sedoM 2* :stinU gnirusaeM 1*
1. N-m:
Newtown Meters
2. kg-cm: Kilogram Centimeters
3. ft-lb: Foot Pounds
4. in-lb: Inch Pounds
1. S: Set Mode
2. P: Peak Mode
3. T: Trace Mode
SPECIFICATIONS
Model Number
ARM601-3
Drive
3/8” Square
Voltage
6 Vdc
Head Type
Quick Release Ratchet
Gear Teeth
45
Length
12-6/16" (315 mm)
Accuracy
CW
±2 % from 20% to 100% of full scale
CCW
±3 % from 20% to 100% of full scale
Operation Range
2-37 ft-lb (3-50 Nm)
Resolution
1 kg-cm, 0.1 N-m, 1 in-lb, 0.1 ft-lb
Operation Mode
Peak / Trace
Auto Shut-Off
After 60 seconds of No Use
Operating Temperature
0-50°C
Storage Temperature
-10-60°C
Battery
AAA (Alkaline) Battery X 4
Tool Weight
1.41 lbs (0.64 kg)
12
16
15
13
14
17
11
