SYMBOLS
The label on your tool may include the following symbols. The symbols and their
definitions are as follows:
SYMBOL NAME EXPLANATION
V Volts Voltage (potential)
n o
No Load Speed No-load Rotational Speed
kg Kilograms Weight
Direct Current Type of Current
…/min
Revolutions per
Minute
Revolutions, Surface Speed, Strokes, etc.
per Minute
FUNCTIONAL DESCRIPTION
CONTROLS AND COMPONENTS:
1. Output Drive 2. Forward / Reverse Lever
3. Aluminum Housing 4. Variable Speed Switch
5. Anti-slip Soft Grip 6. Battery Pack Release Button
7. Battery Pack
1
5
2
3
4
7
6
