I/O Connections
Location: There are three locations on the system that have I/O connections.
(1) The rear of the chassis (integrated into the motherboard)
(2) The front of the chassis (these are optional add on expansion bays)
(3) The rear of the chassis (integrated into the graphics card, as applicable)
(4) The top of the chassis (integrated into the case)
Graphics Card I/O
Connections
Motherboard I/O
Connections
Options I/O
Expansion
Bays
